YT-6600/800/1000/1200 Middle Speed 6 Colors Flexographic Printing Machine
| YT-6600/800/1000/1200 Middle Speed 6 Colors Flexographic Printing Machine |
| Categories: Printing Machine Series |
| Tel: 0086 577-66817170 |
| Mobile: 0086 15858567170 |
| Email: rahsjx@rahsjx.com |
| Songjiadai Industrial Zone, Feiyun Street, Ruian city, Zhejiang,CHINA. |
1.Feature:
1.1 Easy operation, flexible starting, accurate color register .
1.2 The meter counter can set printing quantity according to the requirements, stop the machine
automatically at the quantity or when the material is cut off.
1.3 Pneumatic printing cylinder lift and lower, it will stir the printing ink automatically after lifting.
1.4 The printing ink is spread by the anilox cylinder with even ink color.
1.5 Reliable drying system coordinated with high speed rotation, it will automatically break circuit
when the machine stops.360continuous and adjustable longitudinal register device.
1.6 The frequency control of motor speed adapts to different printing speeds.
1.7 Suitable for printing the packing material as PE and PP plastic bags, glass papers rolling papers, etc.
2.Main technical specification
Model
YT-6600
YT-6800
YT-61000
Max. unwind width
600mm
800mm
1000mm
Msx. print width
560mm
760mm
960mm
Print length
191-914mm
191～914mm
191～914mm
Unwind dameter
ф850mm
ф850mm
ф850mm m
Print Speed
5~70m/min
5～70m/min
5～70m/min
Plate thickness
2.38mm
2.38mm
2.38mm
Total power
13Kw
15 Kw
18Kw
Machine weight
3500kg
4200 kg
5000 kg
INstall dimension
4.8×1.6×2.7m
4.8×1.8×2.7m
4.8×2×2.7m
-
